The Kramer wheel loader 8105 in action.

Wheel Loader 8105 - The intelligent power wheel loader.

The Kramer 8105 wheel loader is part of the 8 Series Premium range and is equipped with the proven Kramer system, an undivided vehicle frame. The machine convinces with strong performance parameters, reliability and comfort while maintaining optimal maneuverability and excellent stability. The unique, powerful engine is available as an option and makes the 8105 a true powerhouse.

Wheel Loader 8105

Benefits at a glance

  • Thrust: A maximun of thrust and best traction by efficient high pressure traction drive and 100% differential lock.
  • Maximum flexibility: The three steering modes front axle steering, all-wheel steering and crab steering are available as standard.
  • Safety: The wide entry on both sides and at the same time exit allows safe ascent and descent.
  • Powerful motor: An absolute high performance loader due to the optional powerful engine of 100 hp.
  • Panoramic cabin: The large cab, including extensive glazing, provides excellent all-round visibility.

Highlights

All-wheel steering

  • High stability even with full steering angle thanks to the undivided frame
  • Maximum maneuverability thanks to steering angles of up to 40° on the front and rear axles
  • Steady payload regardless of steering angle for constant leverage ratios
A rendering of the Kramer wheel loader 8155 in a studio.

EC tractor approval for public road transport

  • Use as towing vehicle with up to 20 t Trailer load
  • No restrictions regarding the load apart from the vehicle's own attachments
  • Road travel with attachments is possible in compliance with legal requirements
Road transport with mounted attachments is possible in compliance with the legal requirements.

Entry and exit on both sides

  • Increased safety due to entry and exit on the side opposite direction of traffic
  • Increased flexibility with entry from both sides
High safety for entry and exit

360° visibility

  • Excellent 360° visibility thanks to large glass panels and narrow cab pillars
  • Panoramic front windshield for an optimal view of the attachment
Kramer wheel loaders have 360° all-round visibility.

Smart Attach fully-hydraulic quickhitch system

  • Coupling of hydraulically driven attachments with the automatic connection of the hydraulic circuit, without the need to get out and in
  • Increased productivity as a result of cost and time savings
  • Attachments changed within seconds for full flexibility
8105

Further Highlights

8105

Color-coded toggle switch for hydraulic, electric, driving and safety functions.

  • Quick operator familiarization when switching drivers
  • Increased safety, as the risk of mistakenly confusing switches is minimized
  • Cross-model operating concept for easy fleet management
Optimum accessibility of all important components for checking the liquid levels

Easy maintenance access

  • Easy access to the engine compartment thanks to the wide-opening engine hood
  • Optimal accessibility of all important components for checking fill levels
  • Quick implementation of service work due to upright-mounted filters and additional maintenance openings
The suspended pedals with the combined brake-inch pedal allow for precise manoeuvring, even at high engine speed.

Combined brake inching pedal

  • Simple and safe operation with combined brake inching pedal
  • Wear-free control of the operating speed even at high engine speeds
  • Maximum work hydraulics even at low operating speeds
Easy coupling and uncoupling of attachments

Pressure release of 3rd control circuit

  • Quick and hassle-free coupling and uncoupling of attachments with auxiliary hydraulic functions while the engine is running
  • Convenient pressure release thanks to optimally placed pushbutton on the loading system
  • Saves time when changing hydraulically operated attachments
Less strain due to the automatic activation of the load stabiliser at high speeds

Load stabilizer with three operating modes

  • Load stabilizer automatically activated at high speeds to reduce wear and tear
  • Automatic deactivation at low speeds for precise control of the loading system
  • Relieving the operator with the automatic function
The suspended pedals with the combined brake-inch pedal allow for precise manoeuvring, even at high engine speed.

Hanging pedals

  • Easy cleaning of the cab floor due to clearance below the pedals
  • Increased operating comfort due to ergonomic arrangement of pedals
  • One-piece, removable floor mat facilitates cleaning
