8115

Wheel Loader 8115 - The rugged heavy-duty wheel loader.

The Kramer 8115 wheel loader belongs to the premium segment of the 8 series and is equipped with the proven principle of the undivided frame. The bucket volume of 1.15 m³ to 1.8 m³ depending on material density paired with the uniquely powerful engine option makes the 8115 a true high performance wheel loader. The optionally available ecospeed transmission and the large tires enable this machine to be used for a wide range of applications.

Wheel Loader 8115

Benefits at a glance

  • ecospeed transmission: The optional ecospeed transmission enables stepless acceleration from 0 km/h to 40km/h.
  • 24 inch tires: An excellent smoothness, best traction and optimum load capacity.
  • Trailer hitch: The height-adjustable trailer coupling is suitable for a towing capacity of up to 14.0 t in combination with the optional air brake system.
  • Long loading system: The optional long loading dock allows for more overload height and range.
  • Versatile use: The Kramer quick hitch system allows quick change of all attachments from the wide range of products.

Highlights

All-wheel steering

  • High stability even with full steering angle thanks to the undivided frame
  • Maximum maneuverability thanks to steering angles of up to 40° on the front and rear axles
  • Steady payload regardless of steering angle for constant leverage ratios
A rendering of the Kramer wheel loader 8155 in a studio.

EC tractor approval for public road transport

  • Use as towing vehicle with up to 20 t Trailer load
  • No restrictions regarding the load apart from the vehicle's own attachments
  • Road travel with attachments is possible in compliance with legal requirements
Road transport with mounted attachments is possible in compliance with the legal requirements.

Entry and exit on both sides

  • Increased safety due to entry and exit on the side opposite direction of traffic
  • Increased flexibility with entry from both sides
High safety for entry and exit

360° visibility

  • Excellent 360° visibility thanks to large glass panels and narrow cab pillars
  • Panoramic front windshield for an optimal view of the attachment
Kramer wheel loaders have 360° all-round visibility.

Smart Attach fully-hydraulic quickhitch system

  • Coupling of hydraulically driven attachments with the automatic connection of the hydraulic circuit, without the need to get out and in
  • Increased productivity as a result of cost and time savings
  • Attachments changed within seconds for full flexibility
8115

Further Highlights

8115

Color-coded toggle switch for hydraulic, electric, driving and safety functions.

  • Quick operator familiarization when switching drivers
  • Increased safety, as the risk of mistakenly confusing switches is minimized
  • Cross-model operating concept for easy fleet management
Optimum accessibility of all important components for checking the liquid levels

Easy maintenance access

  • Easy access to the engine compartment thanks to the wide-opening engine hood
  • Optimal accessibility of all important components for checking fill levels
  • Quick implementation of service work due to upright-mounted filters and additional maintenance openings
The suspended pedals with the combined brake-inch pedal allow for precise manoeuvring, even at high engine speed.

Combined brake inching pedal

  • Simple and safe operation with combined brake inching pedal
  • Wear-free control of the operating speed even at high engine speeds
  • Maximum work hydraulics even at low operating speeds
Easy coupling and uncoupling of attachments

Pressure release of 3rd control circuit

  • Quick and hassle-free coupling and uncoupling of attachments with auxiliary hydraulic functions while the engine is running
  • Convenient pressure release thanks to optimally placed pushbutton on the loading system
  • Saves time when changing hydraulically operated attachments
Less strain due to the automatic activation of the load stabiliser at high speeds

Load stabilizer with three operating modes

  • Load stabilizer automatically activated at high speeds to reduce wear and tear
  • Automatic deactivation at low speeds for precise control of the loading system
  • Relieving the operator with the automatic function
The suspended pedals with the combined brake-inch pedal allow for precise manoeuvring, even at high engine speed.

Hanging pedals

  • Easy cleaning of the cab floor due to clearance below the pedals
  • Increased operating comfort due to ergonomic arrangement of pedals
  • One-piece, removable floor mat facilitates cleaning
