3507

Telehandler 3507 - Strong performance in a compact format.

The Kramer telehandler 3507 is the ideal telehandler for various applications. The telehandler is designed to be compact, has a low overall height and a small turning radius. Despite its dimensions, it can be used in many ways thanks to a stacking height of 7.0 m and 3.5 t of payload. The variable drive system up to a maximum of 40km/h, the 140l/min load-sensing work hydraulics and intelligent driver-assist systems all ensure the 3507 telehandler operates with maximum economic efficiency. The ergonomic and functional cab also ensures stress-free working.

Telehandler 3507

Benefits at a glance

  • Engine: Powerful Deutz engine of EU exhaust stage V with a maximum power of 100 kW (136hp) and a wide-opening engine hood for easy maintenance.
  • Overload height: The telescopic loading system enables a stacking height of 7.0 m.
  • Modern operating concept: 7" LCD display, All-In-One joystick and Jog Dial control element ensure easy machine control.
  • Visibility: The optimal design of the loading system ensures the best view of the attachments and the quick-change plate.
  • All-round visibility: Optional cab elevation by approx. 18 cm with external FOPS grille. The longitudinal struts tilt outward according to the driver's field of vision.

Highlights

360° visibility

  • Excellent 360° visibility thanks to large glass panels and narrow cab pillars
  • Panoramic front windshield for an optimal view of the attachment
Kramer telehandlers have 360° all-round visibility.

Color-coded toggle switch for hydraulic, electric, driving and safety functions.

  • Quick operator familiarization when switching drivers
  • Increased safety, as the risk of mistakenly confusing switches is minimized
  • Cross-model operating concept for easy fleet management
3507

Easy maintenance access

  • Easy access to the engine compartment thanks to the wide-opening engine hood
  • Optimal accessibility of all important components for checking fill levels
  • Quick implementation of service work due to upright-mounted filters and additional maintenance openings
Optimum accessibility to all important components in the engine compartment

7-inch LCD display showing all important operating data and machine settings. Operation is via the jog dial control.

  • Relevant machine data summarized at a glance on the display
  • Operation and setting of machine parameters simple and intuitive via the jog dial
  • Jog dial operation possible while driving
Operation and setting of the machine parameters simple and intuitive via the jog dial

Smart Handling

  • Relief for the driver through partially automated movement of the loading system
  • Increased safety, as the overturning of the vehicle in the longitudinal direction is avoided
  • Increase in efficiency as a result of setting the machine to the relevant working conditions
Relief for the driver through semi-automated movement of the loading system

Further Highlights

Improved all-round visibility for the driver due to the elevated cab.

Two selectable cabin heights

  • Improved all-round visibility for the driver due to the elevated cab
  • Low cab variant for applications with limited clearance heights
The pedals in the footwell are not mounted on the ground.

Hanging pedals

  • Easy cleaning of the cab floor due to clearance below the pedals
  • Increased operating comfort due to ergonomic arrangement of pedals
  • One-piece, removable floor mat facilitates cleaning
Steering column can be adjusted in inclination and usually also in height.

Adjustable steering column

  • Setting of an ergonomically favorable position for each vehicle driver
  • More space to get in and out of the car by folding away the steering wheel
Less strain due to the automatic activation of the load stabiliser at high speeds

Load stabilizer with three operating modes

  • Load stabilizer automatically activated at high speeds to reduce wear and tear
  • Automatic deactivation at low speeds for precise control of the loading system
  • Relieving the operator with the automatic function
Comfortable feeling of space due to wide glass surfaces

Panoramic glazing

  • Optimum visibility over the entire stroke range
  • Pleasant feeling of space due to generous glass surfaces
The suspended pedals with the combined brake-inch pedal allow for precise manoeuvring, even at high engine speed.

Combined brake inching pedal

  • Simple and safe operation with combined brake inching pedal
  • Wear-free control of the operating speed even at high engine speeds
  • Maximum work hydraulics even at low operating speeds
Convenient pressure relief due to optimally placed button on the loading unit

Pressure release of 3rd control circuit

  • Quick and hassle-free coupling and uncoupling of attachments with auxiliary hydraulic functions while the engine is running
  • Convenient pressure release thanks to optimally placed pushbutton on the loading system
  • Saves time when changing hydraulically operated attachments
The central lubricating system ensures regular relubrication of all lubrication points.

Automatic central lubrication system

  • Higher life expectancy and value retention of the machine due to automatic lubrication of all lubrication points
  • Time and cost savings due to low and bundled maintenance of the central lubrication system
  • Optimum lubrication due to adjustable time intervals and grease quantities
