Technical Data
| Drive output | 100 kW |
| Drive output | 136 PS |
| Cylinder capacity | 3,621 cm³ |
| Engine manufacturer | Deutz |
| Exhaust standard level | V |
| Exhaust aftertreatment | DOC / DPF / SCR |
| Bucket capacity (standard bucket) | 1.55 m³ |
| Payload (max.) | 4,200 kg |
| Operating weight | 9,850 - 10,250 kg |
| Payload (S=1.25) | 4,200 kg |
| Payload (S=1.25 extended loader unit) | 3,800 kg |
| Tipping load (standard bucket) | 6,100 kg |
| Tipping load (pallet fork) | 5,250 kg |
| Tank capacity for fuel | 140 l |
| Tank capacity for hydraulic oil | 125 l |
| Travel speed Standard | 0-20 km/h |
| Travel speed Option 1 | 0-30 km/h |
| Travel speed Option 2 | 0-40 km/h |
| Work hydraulics discharge volume (max.) | 150 l/min |
| Kinematics type | PZ |
| Steering angle max. | 40 degree |
| Guaranteed sound power level LwA (cabin) | 102 dB(A) |
| Measured sound power level LwA | 100.7 dB(A) |
| Sound pressure level at the operator's ear | 70 dB(A) |
Vibrations (Uncertainties of measurement as specified in ISO/TR 25398:2006. Please instruct or inform the operator of possible dangers caused by vibrations.): Vibration total value of the upper extremities of the body in m/s² < 2.5 m/s² (< 8.2 feet/s²) and maximum weighted average effective value of acceleration for the body in m/s² < 0.5 m/s² (< 1.64 feet/s²) (on flat and solid ground with the corresponding driving style) and 1.28 m/s² (4.19 feet/s²) (Application in extraction under harsh environmental conditions).
Please note that the product range may vary depending on the country.
The engines shown may differ from the current delivery range in your country. Special equipment is depicted here that may be subject to extra charge. Subject to change without notice.
