The Kramer wheel loader 5075 while transporting a stone pallet.

Wheel Loader 5075 - The rugged champion.

The Kramer 5075 is a compact and maneuverable 5-series wheel loader. The machine impresses with its dynamic all-wheel drive, high payload and low dead weight. With the specially shaped loading system and the P-kinematics, unloading from the second row is possible without any problems. The cabin, designed for functionality, enables safe operation of the most important work functions with the aid of a backlit keypad.

Wheel Loader 5075

Benefits at a glance

  • Automatic load stabilizer: The optional automatic load stabilizer ensures optimum comfort for man and machine.
  • Long loading system: An application-oriented lifting height due to optionally extended loading system.
  • Flexible use: A bucket volume from 0.75 m³ to 1.1 m³ depending on material density.
  • Exhaust gas stage V: Exhaust gas aftertreatment is provided by DOC and DPF.
  • Maneuverability: The 2 x 40° steering angle means minimum turning radius and maneuverability in the smallest area.

Highlights

All-wheel steering

  • High stability even with full steering angle thanks to the undivided frame
  • Maximum maneuverability thanks to steering angles of up to 40° on the front and rear axles
  • Steady payload regardless of steering angle for constant leverage ratios
A rendering of the Kramer wheel loader 8155 in a studio.

360° visibility

  • Excellent 360° visibility thanks to large glass panels and narrow cab pillars
  • Panoramic front windshield for an optimal view of the attachment
Kramer wheel loaders have 360° all-round visibility.

Color-coded toggle switch for hydraulic, electric, driving and safety functions.

  • Quick operator familiarization when switching drivers
  • Increased safety, as the risk of mistakenly confusing switches is minimized
  • Cross-model operating concept for easy fleet management
5075

Smart Attach fully-hydraulic quickhitch system

  • Coupling of hydraulically driven attachments with the automatic connection of the hydraulic circuit, without the need to get out and in
  • Increased productivity as a result of cost and time savings
  • Attachments changed within seconds for full flexibility
5075

Easy maintenance access

  • Easy access to the engine compartment thanks to the wide-opening engine hood
  • Optimal accessibility of all important components for checking fill levels
  • Quick implementation of service work due to upright-mounted filters and additional maintenance openings
Easy access to the engine compartment

Further Highlights

The suspended pedals with the combined brake-inch pedal allow for precise manoeuvring, even at high engine speed.

Combined brake inching pedal

  • Simple and safe operation with combined brake inching pedal
  • Wear-free control of the operating speed even at high engine speeds
  • Maximum work hydraulics even at low operating speeds
Easy coupling and uncoupling of attachments

Pressure release of 3rd control circuit

  • Quick and hassle-free coupling and uncoupling of attachments with auxiliary hydraulic functions while the engine is running
  • Convenient pressure release thanks to optimally placed pushbutton on the loading system
  • Saves time when changing hydraulically operated attachments
Relieve the driver through automatic function

Load stabilizer with three operating modes

  • Load stabilizer automatically activated at high speeds to reduce wear and tear
  • Automatic deactivation at low speeds for precise control of the loading system
  • Relieving the operator with the automatic function
Comfortable feeling of space due to wide glass surfaces

Panoramic glazing

  • Optimum visibility over the entire stroke range
  • Pleasant feeling of space due to generous glass surfaces
The suspended pedals with the combined brake-inch pedal allow for precise manoeuvring, even at high engine speed.

Hanging pedals

  • Easy cleaning of the cab floor due to clearance below the pedals
  • Increased operating comfort due to ergonomic arrangement of pedals
  • One-piece, removable floor mat facilitates cleaning
